2023 Harley-Davidson Road Glide Limited FLTRX REDLINE RED

Stock #069501

510 people have recently viewed it.
In Stock Hi, my name is and I'm interested in this 2023 Harley-Davidson Road Glide Limited FLTRX REDLINE RED . I'm in the area and you can reach me at or on my phone at .




DESCRIPTION

The benchmark for long-distance touring bikes. Runs mile after mile with ease.

  • Upright riding position
  • Floorboards
  • Passenger seat
  • Saddlebags
  • Frame mounted fairing
  • Infotainment
  • Rider safety enhancements available

OVERVIEW

  • Riders looking to cross cities and discover new roads
  • Seeing and being seen with Dual Daymaker LED headlamps
  • Milwaukee-Eight 107 V-Twin engine and sharknose fairing
  • Status:
    New
  • Vehicle:
    2023 Harley-Davidson Road Glide Limited FLTRX REDLINE RED
  • VIN:
    1HD1KHC18PB646224
  • Model Number:
    FLTRX
  • Mileage:
    9 miles
  • Color:
    Redline Red
  • Stock Number:
    069501
  • Location:
    Harley-Davidson of Madison
  • Warranty:
    Not Specified

AUDIO & COMMUNICATION

  • Bluetooth® Audio:
    Yes
  • Brand Name:
    Boom!™ Box 4.3
  • Number Of Speakers:
    2

BRAKES

  • Brake Brand Name:
    Brembo®
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc

CONVENIENCE

  • Engine Immobilizer Brand:
    Digitally Encoded Security System™ (DESS)

ENGINE

  • Bore (in):
    3.94
  • Bore (mm):
    100
  • CAN Liters Per Kilometer (Combined):
    5.5
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    10.0
  • Cooling:
    Oil
  • Cylinders:
    2
  • Displacement (cc):
    1746
  • Displacement (ci):
    107
  • Engine Brand Name:
    Milwaukee-Eight™ 107
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    V Twin
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Premium
  • Fuel Type:
    Gas
  • Starter:
    Electric
  • Stroke (in):
    4.38
  • Stroke (mm):
    111.1
  • Torque (Ft Lbs):
    111
  • Torque (Nm):
    150.5
  • Torque RPM:
    3250
  • US Miles Per Gallon (Combined):
    43
  • Valve Configuration:
    OHV - Pushrod
  • Valves Per Cylinder:
    4
  • Valves:
    8

EXTERIOR

  • Body Material:
    Steel
  • Chassis Protectors:
    Yes
  • Engine Case Guard:
    Yes
  • Floor Board Location:
    Driver
  • Foot Peg Location:
    Passenger
  • Fork Guards:
    Yes
  • Frame:
    Steel
  • Side Cover:
    Yes
  • Stand Type:
    Kick

GLASS

  • Folding:
    Yes
  • Height:
    Low
  • Tinted:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge

LIGHTS

  • Type:
    LED

SEATS

  • Number Of Seats:
    2
  • Seat Height (in):
    27.4
  • Seat Height (mm):
    695
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Leather
  • Seat Type:
    One-Piece

STEERING

  • Steering Control:
    Handlebar

STORAGE

  • Location:
    Left and Right Side
  • Number Of Side Cases:
    2
  • Side Case Material:
    Vinyl

SUSPENSION

  • Air Adjustable:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Suspension Size (in):
    1.9
  • Front Suspension Size (mm):
    49
  • Front Suspension Type:
    Telescopic Fork
  • Number Rear Shock Absorbers:
    2
  • Rear Adjustable Rebound Damping:
    Yes
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Steering Damper:
    Yes

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    372
  • Dry Weight (lbs):
    820
  • Engine Displacement to Weight (cc):
    2.13
  • Fuel Capacity (gal):
    6
  • Fuel Capacity (l):
    22.7
  • Ground Clearance (in):
    5.5
  • Ground Clearance (mm):
    140
  • GVWR (kgs):
    617
  • GVWR (lbs):
    1360
  • Height (in):
    51.6
  • Height (mm):
    1310
  • Length (ft):
    7.98
  • Length (ft/ft):
    7
  • Length (ft/in):
    11.7
  • Length (in):
    95.7
  • Length (mm):
    2430
  • Payload Capacity (kgs):
    229
  • Payload Capacity (lbs):
    505
  • Storage Capacity (cuft):
    2.3
  • Storage Capacity (gal):
    14.8
  • Storage Capacity (l):
    65.1
  • Wet Weight (kg):
    388
  • Wet Weight (lbs):
    855
  • Wheelbase (in):
    64
  • Wheelbase (mm):
    1625
  • Width (in):
    38.6
  • Width (mm):
    980

TRANSMISSION

  • Gear Ratio (1):
    9.593
  • Gear Ratio (2):
    6.65
  • Gear Ratio (3):
    4.938
  • Gear Ratio (4):
    4
  • Gear Ratio (5):
    3.407
  • Gear Ratio (6):
    2.875
  • Number Of Speeds:
    6
  • Primary Drive (Engine / Transmission):
    Chain
  • Primary Drive (Rear Wheel):
    Belt
  • Transmission Type:
    Manual

WHEELS & TIRES

  • Front Tire (Full Spec):
    Dunlop® Harley Davidson Series 130/60 R19 61H
  • Front Tire Aspect Ratio:
    60
  • Front Tire Speed Rating:
    H
  • Front Tire Width:
    130
  • Front Wheel Diameter:
    19
  • Rear Tire (Full Spec):
    Dunlop® Harley Davidson Series 180/55 R18 80H
  • Rear Tire Aspect Ratio:
    55
  • Rear Tire Speed Rating:
    H
  • Rear Tire Width:
    180
  • Rear Wheel Diameter:
    18
  • Tire Brand:
    Dunlop®
  • Wheels Composition:
    Aluminum
